| Display | Type | SVGA TFT LED LCD |
| Viewing Angle (H/V°) | 160/140 | |
| Backlight Life (hrs) | 50,000 hrs | |
| Luminance (cd/m2) | 450 | |
| Size | 12.1" | |
| Max. Resolution | 800 x 600 | |
| Max. Colors | 262 K | |
| Contrast Ratio | 700 : 1 | |
| General | Power Consumption | 20 W (typical) |
| Power Input | 10~29 VDC | |
| Watchdog Timer | 1 ~ 255 sec (system) | |
| Mounting | Desktop, Wall or Panel Mount | |
| Certifications | BSMI, CCC, CE, FCC Class A, UL | |
| Dimensions | 311 x 237 x 71.6 mm (12.24" x 9.33" x 2.82") | |
| BIOS | AMI 8Mbit | |
| Cooling System | Fanless design | |
| Enclosure Housing | Front bezel: Die-cast Aluminum alloy, Back housing: PC/ABS Resin | |
| OS Support | Microsoft® Windows® 7/XPE/WES/Windows CE 6.0 | |
| Weight (Net) | 4.57 kg (10.07 lbs) | |
| System Hardware | CPU | Intel® Atom™ D525 1.8 GHz with 1MB cache |
| Memory | 4GB SO-DIMM DDR3 SDRAM | |
| Storage | CompactFlash® slot x 1, 2.5" SATA HDD x 1(optional) | |
| Chipset | ICH8M | |
| LAN | 10/100/1000Base-T x 2 | |
| I/O | RS-232 x 2 with isolation, RS-422/485 x 1 with isolation and auto data flow control, USB 2.0 x 2 (Host), PS/2 x 1 | |
| Expansion Slots | Full-size PCI-E and Mini PCI-E | |
| DI/DO & Backup SRAM | 8 x DI/DO with isolation and backup 1MB SRAM | |
| Environment | Temperature (Operating) | 0 ~ 55°C (32 ~ 131°F) |
| Temperature (Storage) | -20 ~ 60° C (-4 ~ 140° F) | |
| Humidity (Operating) | 10 ~ 95% RH @ 40° C, non-condensing | |
| Ingress Protection | Front panel: IP65 | |
| Vibration Protection | With HDD: 1 Grms (5 ~ 500 Hz) | |
| Touchscreen | Lifespan | 10 million touches at single point |
| Light Transmission | Above 75% | |
| Resolution | Linearity | |
| Touch Type | 5-wire, analog resistive |
